OP2803A 28mm 3CCD Lens for Redefine Color Reduction
DESCRIPTION
Designed for 3CCD cameras, redefining color reproduction
Working distance from 0.4m-2m
Compatible with the maximum format of 蠁30
Low distortion, full field of view distortion < 0.2%
Applied to projects with high color requirements, such as color sorting, etc.
SENSOR
The IMX990/991 is a diagonal 8.2 mm (Type 1/2) CMOS active pixel type solid-state image sensor with a square pixel array and 1.31M effective pixels. This chip features a global shutter with variable charge-integration time. This chip has a wide waveband (0.4 碌m to 1.7 碌m) with high sensitivity, high resolution, low dark current and low power consumption.
Applications: Products Sorting, Foreign Material Inspection, Semiconductor Inspection, Temperature Estimation, Remote Observation.
PARAMETER
Aperture |
2.8-16 |
---|---|
Distortion [%] |
<0.4% |
Sensor size |
30 |
Focal Length [mm] |
28 |
Magnification |
0.01X-0.14X |
MOD |
0.4m-2m |
FOV Angle |
55掳 |
Flange Distance |
46.5 |
Filter Size |
M62脳P0.75 |
Mount |
F-mount |
Relative illumination |
0.8 |
Size |
蠁64脳93.9 |
|
|
APPLICATION
Food Color recognition
Electronic parts Identify existence
Automobile
Textile
DRAWING
