845nm Near-IR Bandpass Filter

Bandpass Filter

Description:

845nm bandpass filters are designed to provide excellent transmission at 850nm while blocking visible and lower near-IR wavelength transmission. At the same time, it will block longer wavelength near-IR light – particularly at 940nm. In covert or other near-IR applications where more than one near-IR light source is desired (typically 850nm and 940nm would be two common choices), 845nm can be used with cameras and lighting designed to capture 850nm images and will block unwanted/interfering 940nm illumination.

Parameter:

Useful Range : 830-865nm

FWHM : 60nm

Tolerance : +/- 10nm

Peak Transmission : ≥90%

Surface Quality : 40/20

Compatible LED : 840nm, 850nm

Thickness : 1mm

Application:

Machine Vision
